Dorma Universal Patch Fittings

Dorma Universal Patch Fittings

These fittings are supplied as standard with gasket to suit 10 mm glass. For 8 mm and 12 mm glass, correspondingly thicker and thinner gaskets are available.

Suitable for most applications
The inserts for corner and overpanel patches in the DORMA Universal program range have been designed and manufactured to give two options forin the pivot point distance from the sidepanel sidelight or frame.
It can be – either 55 mm or 65 mm.

Matching range of locks
The DORMA Universal range includes every type of accessory, and of course, a variety of locks and strike boxes in a matching design concept, giving the designer plenty of choice from the options available.



PT 10 – Bottom Patch Fitting

PT 10 - Bottom Patch Fitting

Finish
Polished stainless steel

Glass thickness
10, 12mm








PT 20 - Top Patch FittingPT 20 – Top Patch Fitting

Finish
Polished stainless steel

Glass thickness
10, 12mm




PT 30 - Overpanel PatchPT 30 – Overpanel Patch

With pivot 15mm ø
With M 8 tapped hole at side

Finish
Polished stainless steel

Glass thickness
10, 12mm


PT 40 - Over / Slide PanelPT 40 – Over / Slide Panel

With pivot 15mm ø

Finish
Polished stainless steel

Glass thickness
10, 12mm


PT 41 - Top Patch FittingPT 41 – Top Patch Fitting

Finish
Polished stainless steel

Glass thickness
10, 12mm




US 10 - Corner LockUS 10 – Corner Lock

Finish
Polished stainless steel

Glass thickness
10, 12mm




PT 24 - Top PivotACCESSORIES – PT 24 – Top Pivot

Application
For aluminium, steel or timber door

Finish
Polished stainless steel
